MiG-19P FarmerDCS WORLD Startup Checklist · 110 steps
0%
Wikimedia CommonsCC BY-SA 4.0
FighterCold War
AIRCRAFT BRIEF
The Mikoyan-Gurevich MiG-19 was the Soviet Union's first production supersonic fighter and the world's first mass-produced aircraft to exceed Mach 1 in level flight. Entering service in 1955, the 'P' variant added the RP-1 Izumrud radar for all-weather interception capability. Though quickly superseded by the MiG-21, it served extensively in the Vietnam War (as the Chinese-built J-6) and proved lethal in dogfights against more modern Western fighters.
SPECIFICATIONS
manufacturerMikoyan-Gurevich
first Flight1953
roleInterceptor / Fighter
crew1 pilot
engines2x Tumansky RD-9B (7,165 lbf each with AB)
max Speed1,452 km/h (Mach 1.35)
range1,370 km (740 nmi)
ceiling57,400 ft
weight8,832 kg (MTOW)
PHS 1 — Electrical / Pre-Start6 steps
| 01 | Throttles (Both) | OFF | |
| 02 | Parking Brake | SET | |
| 03 | Batteries (Both) | ON | |
| 04 | Ground Power | CONNECT | |
| 05 | Fuel System | CHECK — All tanks ON | |
| 06 | Fuel Quantity | CHECK — Adequate |
PHS 2 — Systems Setup7 steps
| 01 | Radio (RSIU-4V) | ON — Set channel | |
| 02 | Navigation Lights | AS REQUIRED | |
| 03 | Anti-Skid | ON | |
| 04 | Heat / Anti-Ice | AS REQUIRED | |
| 05 | Fire Extinguisher | ON | |
| 06 | Engine Start System | ON | |
| 07 | Generators (Both) | ON |
PHS 3 — Engine Start9 steps
| 01 | Left Throttle | IDLE | |
| 02 | Left Engine Start ButtonNOTE: Tumansky RD-9B turbojet starts. | PRESS | |
| 03 | Left EngineWARNING: EGT must not exceed 650°C during start. | MONITOR — RPM, EGT | |
| 04 | Left Engine Stabilize | CHECK — Idle RPM ~45% | |
| 05 | Ground Power | DISCONNECT | |
| 06 | Right Throttle | IDLE | |
| 07 | Right Engine Start Button | PRESS | |
| 08 | Right Engine | MONITOR — RPM, EGT | |
| 09 | Right Engine Stabilize | CHECK — Idle RPM ~45% |
PHS 4 — Post-Start / Systems7 steps
| 01 | Generators | VERIFY ON (Both) | |
| 02 | Hydraulic Pressure | CHECK — Normal | |
| 03 | Flight Controls | CYCLE — Stick and rudder full travel | |
| 04 | Trim | SET — Takeoff | |
| 05 | Flaps | CHECK — Cycle and return | |
| 06 | Air Brake | CHECK — Extend and retract | |
| 07 | NWS | ON |
PHS 5 — Avionics / Navigation8 steps
| 01 | SPO (RWR) | ON | |
| 02 | Radar (RP-5 Izumrud)NOTE: Search and track radar — allow warm-up. | STBY | |
| 03 | ARK (ADF) | ON — Set frequency | |
| 04 | SOD (IFF) | ON | |
| 05 | Gunsight (ASP-5N) | ON — Set mode | |
| 06 | Altimeter | SET — Field elevation / QFE | |
| 07 | Gyro / Compass | SET heading | |
| 08 | Master Arm | SAFE |
PHS 6 — Before Taxi7 steps
| 01 | Canopy | CLOSE & LOCK | |
| 02 | Ejection SeatWARNING: Verify canopy locked before arming. | ARM | |
| 03 | Pitot Heat | ON | |
| 04 | Taxi Light | ON | |
| 05 | Anti-Collision Light | ON | |
| 06 | Parking Brake | RELEASE | |
| 07 | Brakes | CHECK |
PHS 7 — Taxi4 steps
| 01 | NWS | CHECK responsive | |
| 02 | Taxi Speed | SAFE — max 15 kts | |
| 03 | Instruments | CHECK during taxi | |
| 04 | Flight Controls | FREE & CORRECT |
PHS 8 — Before Takeoff8 steps
| 01 | Canopy | CONFIRM LOCKED | |
| 02 | Ejection Seat | CONFIRM ARMED | |
| 03 | Flaps | SET — Takeoff (15°) | |
| 04 | Trim | SET — Takeoff | |
| 05 | Radar | OPR (if warm) | |
| 06 | Altimeter | SET | |
| 07 | Fuel Quantity | CHECK — Adequate | |
| 08 | Master Arm | SAFE |
PHS 9 — Takeoff10 steps
| 01 | Lineup on Runway | CENTERLINE | |
| 02 | Brakes | HOLD | |
| 03 | ThrottlesNOTE: Check engine instruments. | MIL POWER (Both) | |
| 04 | Brakes | RELEASE | |
| 05 | Throttles | AFTERBURNER (if required) | |
| 06 | NWSCAUTION: MiG-19 tends to yaw on takeoff — use rudder aggressively. | MAINTAIN centerline | |
| 07 | Rotation | ROTATE at 280–320 km/h | |
| 08 | Positive Climb | CONFIRMED | |
| 09 | Landing Gear | UP | |
| 10 | Flaps | RETRACT (above 400 km/h) |
PHS 10 — After Takeoff / Climb6 steps
| 01 | Landing Gear | CONFIRM UP | |
| 02 | Flaps | CONFIRM RETRACTED | |
| 03 | Airspeed | ACCELERATE to 500 km/h | |
| 04 | Throttles | MIL or as required | |
| 05 | Altimeter | CHECK | |
| 06 | Taxi Light | OFF |
PHS 11 — Cruise / Transit6 steps
| 01 | Altitude | AT assigned level | |
| 02 | AirspeedNOTE: Max Mach 1.35. Cruise ~800 km/h. | AS REQUIRED | |
| 03 | Fuel StateNOTE: MiG-19 has very limited fuel — monitor constantly. | MONITOR | |
| 04 | Navigation (ARK) | CHECK | |
| 05 | SPO (RWR) | MONITOR | |
| 06 | Engine Instruments | SCAN — Both engines |
PHS 12 — Descent / Approach7 steps
| 01 | Airspeed | REDUCE below 500 km/h | |
| 02 | Altimeter | SET — Local QFE | |
| 03 | Approach Speed | ~350 km/h | |
| 04 | Landing Gear | DOWN (below 450 km/h) | |
| 05 | Flaps | DOWN — Full | |
| 06 | Landing Light | ON | |
| 07 | Master Arm | SAFE |
PHS 13 — Landing6 steps
| 01 | Approach Speed | MAINTAIN ~320 km/h | |
| 02 | Throttles | IDLE at touchdown | |
| 03 | Nosewheel | LOWER gently | |
| 04 | Drag Chute | DEPLOY | |
| 05 | Braking | APPLY | |
| 06 | NWS | ENGAGE below 150 km/h |
PHS 14 — After Landing5 steps
| 01 | Drag Chute | JETTISON | |
| 02 | Flaps | RETRACT | |
| 03 | Radar | STBY | |
| 04 | SOD (IFF) | STBY | |
| 05 | Taxi to Parking | NWS ENGAGED |
PHS 15 — Shutdown14 steps
| 01 | Parking Brake | SET | |
| 02 | Radar | OFF | |
| 03 | SPO (RWR) | OFF | |
| 04 | Radio | OFF | |
| 05 | ARK (ADF) | OFF | |
| 06 | Gunsight | OFF | |
| 07 | SOD (IFF) | OFF | |
| 08 | Ejection SeatWARNING: Safe seat before ground crew approach. | SAFE | |
| 09 | Left Throttle | OFF | |
| 10 | Right Throttle | OFF | |
| 11 | Generators | OFF | |
| 12 | All Lights | OFF | |
| 13 | Batteries | OFF | |
| 14 | Canopy | OPEN |
